AIKON F4 Betaflight Flight Controller OSD STM32F405 2-6S 30.5*30.5mm for RC Drone FPV Racing - 32.00 €

Seller: Banggood,

Free shipping aviable, Registered postage from 25 €

AIKON F4 Betaflight Flight Controller OSD STM32F405 2-6S 30.5*30.5mm for RC Drone FPV Racing

Specification:
Brand name: Aikon
Item name: F4 flight controller
Lipo: 2-6s
Mounting Hole: 30.5*30.5mm
Firmware: Betaflight AIKONF4 Target
MCU: STM32F405
IMU: ICM-20602

IMU: ICM-20602

Motor outputs: 4-6 IMU

Interrupt: Yes

BARO: Optionally

VCP: Yes

Hardware UARTS:
- UART1 for SerialRX,
- UART4 for SPORT,
- UART2 and UART3 available for general use
Software serial: SOFTSERIAL1 for VTX control, SOFTSERIAL2 for ESC telemetry

OSD: Yes

Blackbox: SPI 16MB

PPM/LED_STRIP Shared: Yes

Battery Voltage Sensor: Yes

Integrated Voltage Regulator: Yes

Buttons: Boot

Blackbox: SPI 16MB
Weight: 7g

Package Included:
1 x F4 Flight Controller
6 x Rubber Grommets
1 x 10pin FC to ESC Cable
