Specification:
Brand name: AIKON
Item name: AK32 Flytower MINI & 35A Blheli_32 2-6S Brushless ESC
Flight Controller
MCU: STM32F405
IMU: ICM-20602
Motor outputs: 4-6 IMU
Interrupt: Yes
BARO: Optionally
VCP: Yes
Hardware UARTS: UART1 for SerialRX, UART4 for SPORT, UART2 and UART3 available for general use
Software serial: SOFTSERIAL1 for VTX control, SOFTSERIAL2 for ESC telemetry
Software serial: SOFTSERIAL1 for VTX control, SOFTSERIAL2 for ESC telemetry
OSD: Yes
Blackbox: SPI 16MB
PPM/LED_STRIP Shared: Yes
Battery Voltage Sensor: Yes
Integrated Voltage Regulator: Yes
Buttons: Boot
35A Blheli_32 2-6S Brushless ESC
Battery: 2-6S
Constant Current: 35A
Burst Current: 45A
BEC: 5V/3A
Firmware: Blheli_32
MCU: STM32PIN F0
Bootloader: Yes
Signal wire length: 100mm
Battery wire length: 150mm
Weight( with/wire): 15g
Package Included:
1 x AK32 Flytower MINI
1 x 35A Blheli_32 2-6S Brushless ESC
35A Blheli_32 2-6S Brushless ESC
Battery: 2-6S
Constant Current: 35A
Burst Current: 45A
BEC: 5V/3A
Firmware: Blheli_32
MCU: STM32PIN F0
Bootloader: Yes
Signal wire length: 100mm
Battery wire length: 150mm
Weight( with/wire): 15g
Package Included:
1 x AK32 Flytower MINI
1 x 35A Blheli_32 2-6S Brushless ESC
