Specification:
Brand name: AGFRC
Item name: MRF16CH receiver
Operating Voltage: 4.8V~8.4V
Dimension: 26x19.2x5mm (exclude antenna)
Weight: 3.8g
Antenna: Dual-antenna
Communication Data: Bidirection Communication
Output Channels: S-BUS (16CH) + CPPMR (8CH) + RSSI (PWM)
Compatibility:
Compatible OPEN TX FRSKY D16 remote control system
Suitable for FRSKY X9D, X9DP, X9E, X12S etc. D16 supported remote control
Feature:
1) High quality PA to ensure high receiving sensitivity;
2) Dual-antenna design, available to mount in different angle to increase the reception reliability;
3) Dual serial signal S-BUS/PPM (8CH) output, connect directly to flight control system, especially for mini multirotor and aircraft to save mounting space;
4) RSSI(PWM) output, available to detect the signal changes of the radio control via receiver.
Bind Procedure:
1. Turn on transmitter, select MENU and enter MODEL SETUP, select D16 mode and start BIND function;
2. Press and hold the SW on the receiver and power on, the GREEN LED on and RED change to flash means bind completely.
3. Transmitter exit BIND function, power-on again the receiver, GREEN LED on means BING successfully;
4. If failed binding, please repeat above steps.
LED Status:
| GREEN LED | RED LED | Status |
| Off | Blink | No signal reception |
| Solid | Fast flash | Complete bind |
| Solid | Off | Receiving signals |
Package included:
1x MRF16CH receiver
