AAI RQ-7 Shadow 2000mm Wingspan Laser Cut FPV Aircraft Kit
In real life, the AAI RQ-7 Shadow is a battlefield UAV used by the armed forces of Australia, Italy, Sweden, the United States and others to provide a reconnaissance, surveillance and as a target acquisition platform.
Over 500 RQ-7 Shadows are in operational use throughout the world carrying electro-optic/infrared imaging sensors and having a range of over 100km and a 4 hour on-target loiter time. The specifications also required the UAV to be able to land in a sports field.
Our RQ-7 Shadow can't offer a 4 hour duration or a 100km range, but it is certainly a fantastic FPV platform with all of the highly practical features of the full size, including the aerodynamically proven inverted V tail, twin boom layout, center mounted pusher motor, fixed tricycle undercarriage and the huge central nacelle giving a clear view for your cameras and sensors.
For the scale enthusiasts among us the kit builds into quite an accurate representation of the full size Shadow and, at 2000mm wingspan the large scale enthusiasts won't be dissappointed either as this one is very nearly 1/2 scale!
Description:
Item Name: AAI RQ-7 Shadow
Wingspan: 2000mm
Length: 1630mm
Flying weight: 3200~4000g
Features:
• Highly capable FPV platform
• Accurate laser cut parts
• Quality balsa and plywood construction
• Easy to follow manual
• Large payload capacity
Note:
This item only includes the wooden parts,not includes any hardware,carbon fiber wing spar or tubes,even the two aluminum tail tubes in the pictures are not included.
To Complete This Airplane You Will Need(Not Included):
15x 1.5mm 1000*100 balsa wood board
3x 1mm balsa 1000*100 wood board
2x 20*19*1000 carbon tube (weight<100g)
1x 14*12*1000 carbon tube
1x 8*6 or 8*6*1000 carbon tube
4x Inner diameter 20mm aluminum snap
1x 26-30cc 3D airplane landing gear
1x Wire diameter 4-5mm front landing gear
1x 4m airplane covering film
1x Other Metal parts
1x Other electronic devices
Recommended Electronic Parts(Not Included):
Radio: 4 channel minimum
Motor: 2820 900-1100KV brushless outrunner
ESC: 60A
Propeller: 12 x 6
Servo: 2 x 17g servos, 2 x standard servos
5000-10000mAh 4S LiPoly battery
Choice of FPV equipment (optional)
Recommended FPV System (Not Included):
APM Flight Controller Set 2.8
Eachine 700TVL 1/3 Cmos 110 Degree Lens Camera
Skyzone FPV 5.8G 32CH 7 Inch Monitor DVR
Eachine TS832 FPV 5.8G 32CH 600mW Wireless AV Transmitter
Eachine FPV 5.8G 32CH Wireless AV Receiver RC832
5.8G Gain Petals Clover Mushrooms
Package included:
1x AAI RQ-7 Shadow 2000mm Wingspan Laser Cut FPV Aircraft Kit(only the wooden part)
