Description:
Module Properties: non-isolated constant current and voltage module
Rectification: non-synchronous rectification
Input voltage: 5V-30V
Output voltage: 0.8V-29V
Output current: adjustable maximum 5A
Conversion efficiency: 95% (the highest)
Switching frequency: 300KHz
Output ripple: 50mV (max) 20M bandwidth
Load Regulation: 0.5%
Voltage Regulation: 2.5%
Operating Temperature: -40to +85
Measurement Accuracy: 0.1%
Refresh rate: about 200ms one time
Display: 0.28"digital tube
Current: 0A-5A
voltage: 5V-30V
working current: Less than 15mA
Display Color: red
Input impedance: 50mΩ
Size: 51 * 26.3 * 14 (L * W * H) (mm)
Weight:32g
Notice:Please connect right as the printed :"IN-,IN+,OUT-, OUT+", or the Module will be burned.
Package includes:
1 x LED Panel Voltmeter Ammeter
