5.8G 2W 33dBm Signal Amplifier Gain Controllable Compatible Multi FPV VTX Transmitter
Description
Working Voltage : 6V-23V
Working Frequency : 5.00 GHZ – 6.00GHZ
Max. Power Input : 27dBm(5.8G TX which in -3dBm-27dBm can use this booster directly)
Max. Transmission Power : 33dBm (2w)
Gain Adjustmeng Range : 3dB-6dB @ 5.60GHZ-5.75GHZ/5dB-8dB @ 5.75GHZ-5.85GHZ/3dB-7dB @ 5.85GHZ-6.00GHZ(if there is cooling fan, the gain will be 2dB higher,eg 5dB-8dB will be 7dB-10dB )
Weight : 40g (can remove the cooing chip to reduce the weight)
Size : 44mm*27mm*28mm
Feature
The first 5.8G signal amplifier which can adjust the gain range
Transmission power is controllable. In the case of short distance you can choose a lower transmission power to save battery life.
Small and light, only 44mm*27mm*28mm.
Transmission Power up to 2W
With double cooling chip, support long-term reliable work without cooling fan.
Built-in high performance stabilizing module, work stable in 6V-23V
Good compatibility. Compatible with all 5.8G VTX which transmission power is not more than 27dBm
Package Included
1 x 5.8G Signal Amplifier
