4X Racerstar Tattoo+ 52A BLheli_32 RC Drone FPV Racing ESC Dshot1200 + 4X Garila X2507 1500KV Brushless Motor - 146.99 €

4X Racerstar Tattoo+ 52A BLheli_32 RC Drone FPV Racing ESC Dshot1200 + 4X Garila X2507 1500KV Brushless Motor
Seller: Banggood,
Free shipping aviable, Registered postage from 25 €

4X Racerstar Tattoo+ 52A BLheli_32 FPV Racing ESC Dshot1200 + 4X Garila X2507 1500KV Brushless Motor



Specification:

1500KV motor:
Brand name: Garila
Stator Diameter: 25.0 mm (0.945 in)
Stator Thickness: 7.0 mm(0.236 in)
No. of Stator Arms: 12
Magnet Poles: 14
Motor KV: 1500 RPM / Volt
No-Load Current (Io/12V): 0.95Amps
Motor Resistance (Rm): 58.5mΩ
Maximum Continuous Current: 12Vx29.7A / 356W (3 Lipo) 16Vx30A / 480W (4 Lipo)
Weight: 42.5 Grams (1.5oz)
Outside Diameter: 31.54 mm (1.24 in)
Shaft Diameter(inside): 4.0 mm (0.157 in)
Prop Shaft Diameter(outside): 5.0 mm (0.197 in)
Body Length: 18.5mm (0.73 in)
Overall Shaft Length: 32.5 mm (1.28 in)
Max LiPoly Cell: 4~6s
Prop: 6~7 inch
Drive Frequency: 1.68 kHz


Tattoo+ 52A ESC:
BL_32 GD 52A
Con. current: 52A
Peak current (10s): 58A
LBEC: NO
SBEC: NO
Lipo: 2-6s
Programming: YES
Weight: 8g
Size(PCB):35*20mm
Current detection, RGBLED telemetry
MCU: GD32F150
Frequency range: 72MHz

Package Included:
4 x X2507 motor
4 x Racerstar Tattoo+ BL_32 52A ESC
4 x M5 flanged lock nut. 16+2 x M3*6 screws
