4X DYS BE1806 2300KV Brushless Motor with 4X DYS BL16A Mini 16A BLHeli ESC
DYS BE1806 2300KV Brushless Motor ( Black )
Description:
Brand: DYS
Item No: BE1806
Item name: 1806 2300KV Brushless Motor
Color:Black
Height: 0.85 inches (21.5mm)
Width: 0.90 inches (23mm)
Weight: 18 grams
RPM/V: 2300KV
Battery: 2-3S lithium polymer
Mounting pattern: 2x 12mm and 2x 16mm
Motor mount hole size: M2
Output shaft diameter: 2
Voltage: 2-3S
Max.current: 7.6A
Max.power: 84.4W
Thrust:
210 Grams (5030 w/ 2S @ 4.4A)
375 Grams (5030 w/ 3S @ 8.0A)
485 Grams (6030 w/ 3S @ 11.0A)
Features:
Low vibration motor great for flying
To make aircraft more stable
Less operating noise
More efficient
Bearings long life
DYS BL16A 16A BLHeli ESC
Description:
Brand: DYS
Item Name:BL16A ESC
BEC: NO
Input voltage: 2-4s Lipo
Signal Frequency:20-500Hz
Outout PWM Frequency:18KHz
Come with BLHeli:Yes
Application:Compatible with SimonK and BLHeli
Size(LxWxH):23x12x4.5mm
Weight:7.6g
Features:
Specially for Multi-copter, throttle respond fast;
Suit for throttle, which can compatible well with motor;
Throttle signal is twisted pair cable, reduce the crosstalk while the signal transfer by the copper wire and flight more stable;
The maximum refresh frequency up to 500Hz throttle signal, compatible with all flight controls;
Use new process ultra-low resistance MOSFET with miniaturization, and all flashes are N MOS with high withstanding current;
Minaturization design, SN16/20A with high performance capacitor fliter on the board, weight reduce to 2g, also already thicken the PCB copper specially and low heat for small
Package included:
4 X DYS BE1806 2300KV Motor (Black)
4 X DYS BL16A ESC
