4 PCS Dual Row 6 Bits WS2812B RGB5050 Night LED Trip Programmer by Betaflight for RC Drone
Specification:
Item Name: Dual Row 6 Bits WS2812B RGB5050 Night LED Trip
Input Voltage: 5V
Size: 31x12mm
Weight:1.8g/PC
Quantity: 4 PCS
Connection Mode: via 1mm Connection Cable with Dual Port ( Included in package)
Usage:
There are 4 PCS LED Strip, all of them are having " Input" Port and " Output " Port.
1. Remark 1 , 2, 3, 4 for these LED Strips
2. Supply 5V to first LED Stip, which was remark "1". There are 3 cables of " Input Port" for this LED Srtip, which would be connected
to Flight Controller Board's " GND" , "5V" and "LED Signal" Port.
3. Then remarked "1" LED Strip Output Port connects to " 2" LED Strip Input Port.
4. 2" LED Strip Output Port connects to "3" LED Strip Input Port.
5. "3" LED Strip Output Strip connects to "4" LED Input Port ( Like the Second Photo showed)
6. Finally. connects the Flight Controller to betaflight and then enter into the LED Programmer Setting.
7. After finishing the setting, installing the LED on the RC Drne would be ok.
Quantity: 4 PCS
Connection Mode: via 1mm Connection Cable with Dual Port ( Included in package)
Usage:
There are 4 PCS LED Strip, all of them are having " Input" Port and " Output " Port.
1. Remark 1 , 2, 3, 4 for these LED Strips
2. Supply 5V to first LED Stip, which was remark "1". There are 3 cables of " Input Port" for this LED Srtip, which would be connected
to Flight Controller Board's " GND" , "5V" and "LED Signal" Port.
3. Then remarked "1" LED Strip Output Port connects to " 2" LED Strip Input Port.
4. 2" LED Strip Output Port connects to "3" LED Strip Input Port.
5. "3" LED Strip Output Strip connects to "4" LED Input Port ( Like the Second Photo showed)
6. Finally. connects the Flight Controller to betaflight and then enter into the LED Programmer Setting.
7. After finishing the setting, installing the LED on the RC Drne would be ok.
Package Included:
4x LED Strip
4x Cable
4x Cable
