FPV Racing F7 Flight Controller STM32F745VGT6 100lqfp 216MHz MPU6000 SPI
Specification:
STM32F745VGT6 100lqfp 216MHz
MPU6000 SPI
All 8 uarts available + VCP
10 pwm outputs + 6 inputs
external I2C
external SPI (shared with U4/5)
support for CAN
SD card logging (SPI)
3 AD channels, one with 10k/1k divider, two with 1k series resistor
with a 36x36mm Layout and 30.5x30.5mm Hole Setup
Weight 7.4g
Note: Firmware adress, .
Package Included:
1 X F7 flight controller
1 X Cable set
