20x20mm XJB F410 Dshot Flytower Micro F4 AIO OSD BEC Flight Control & 10A Blheli_S 2-3S 4 In 1 ESC
Specification:
Item Name: 20x20mm XJB F410 Dshot Flytower Micro F4 AIO OSD BEC Flight Control & 10A Blheli_S 2-3S 4 In 1 ESC
Model: XJB F410
Weight: 6.5g
Usage: for 65mm-250mm Frame Kit
Micro F4 Flight Control Board ( D-Shot Version):
MPU: MPU6000-SPI
CPU: STM32F405RGT6, dual 8K.
Black Box: Flash 16M
Black Box: Flash 16M
Input Voltage: 2-4S Lipo
Built-in Betaflight OSD to adjust PID
Built-in Betaflight OSD to adjust PID
BEC Output: 5V@3A
Size: 25x25mm board, 20mm mounting holes (M2)
Weight:2.3g
Support Subs/PPM/DSMX receiver
10A 2-3S Blheli_S BB2 4 in 1 ESC:
Input Voltage: 2-3S Lipo battery
Constant Current: 10A
Peak Current: 30A (10S)
BEC Ouput: NO
Firmware: BLheli_S 16.5
Size: 27x22mm (main board)
30x27mm ( including pad)
Installing Hole: 20x20mm
Installing Hole: 20x20mm
Weight: 4.2g
CPU: SILABS EFM8BB2 48MHZ
MOS Tube: TOP QUALITY MOSFET
Firmware: Betaflight 16.5
Firmware: Betaflight 16.5
Support Damped Mode, Oneshot125, Oneshot42, Multishot, Dshot150, Dshot300, Dshot600, forward and reverse
Package Included:
1x F4 AIO OSD BEC Flight Control Board
1x 10A Blheli_S 4 In 1 ESC
Package Included:
1x F4 AIO OSD BEC Flight Control Board
1x 10A Blheli_S 4 In 1 ESC
