2 PCS 3Bhobby 3B-R 1408 Brushless Motor 3200KV 3600KV 3-4S For RC Drone FPV Racing Multi Rotor
Description:
Brand name: 3BHOBBY
KV: 3200KV/3600KV
No.of cells(Lipo): 3S-4S
Stator diameter: 14mm
Stator length: 8mm
Shaft diameter: 5mm
Motor dimension (Dia.*Len): Φ19×29.3mm
Weight: 14.9g (excluding cable)
Wire szie: 24AWG 80mm
Recommend propeller: Gemfan 3-4″
Recommend ESC: 20-30A
Suit for: 120-130 frame
Specifications | DATA | |
Motor KV | 3200KV | 3600KV |
Stator Diameter | 14mm | 14mm |
Stator Thickness | 8mm | 8mm |
No.of Stator Arms | 9S | 9S |
No.of Rotor poles | 12P | 12P |
No-load Current(A/10V) | 0.75A | 0.8A |
Motor Resistance | 129mΩ | 102mΩ |
Max Continuous Current | 19.8A | 19.84A |
Max Continuous Power | 239.7W | 318W |
Weight | 15.3g | 15.3g |
Rotor Diameter | 19mm | 19mm |
Shaft Diameter | 5mm | 5mm |
Body Length | 16.3mm | 16.3mm |
Overall shaft Length | 29.3mm | 29.3mm |
No.of Cells(Lipo) | 3~4S | 3~4S |
ESC | 20~30A | 20~30A |
Recommended Prop(inch) | 3~4Inch | 3~3.1Inch |
Wire Szie | 24AWG 80mm | 24AWG 80mm |
Package included:
2 x 1408 motor
4 x aluminium nut
12 x round head hex socket screws M2*5
