Specification:
Item Name: Omnibus F4 FC Integrated with Betaflight OSD
Model: TeenyF4 Pro
Processor: STM32F405RGT6
Sensor: MPU-6000 (connected by SPI)
Firmware version: betaflight_3.2.0_OMNIBUSF4SD
Input Voltage: 1-2S Lipo
Setting Notice:Input Voltage: 1-2S Lipo
Size: 20*20mm
Mounting Hole: 16*16mm
Mount Hole Diameter: 2mm
Weight: 2.2g
- Built-in Buck-Boost Converter
- Built-in Buck-Boost Converter
- Receiver: PPM, IBUS, SBUS, DSM2, DSMX etc.
- Suitable for Micro FPV brushless frame
Features:
-Support programmable LED Strip (turn off transponder before using)
-Support BLheli/BLHELI_S suite Pass-through ready
-Support PPM,Oneshot125, Oneshot42, Multishot, Dshot150, Dshot300, Dshot600
-Support the newest DSHOT ESC
-Built-in voltage detection, alarm
-Built-in Betaflight-OSD , Configure by Betaflight GUI
-Buzzer Ready (Solder pin)
-LED_STRIP Ready (Solder pin)
Features:
-Support programmable LED Strip (turn off transponder before using)
-Support BLheli/BLHELI_S suite Pass-through ready
-Support PPM,Oneshot125, Oneshot42, Multishot, Dshot150, Dshot300, Dshot600
-Support the newest DSHOT ESC
-Built-in voltage detection, alarm
-Built-in Betaflight-OSD , Configure by Betaflight GUI
-Buzzer Ready (Solder pin)
-LED_STRIP Ready (Solder pin)
- SBUS/IBUS/DSMX receiver please configure RX1 (UART1) as input, and enable Serial_RX
- PPM receiver don’t need to enable Serial_RX
- DSM/DSM2/DSMX receiver power from 3.3V
- SBUS and PPM receiver power from 5V
Package Included:
Package Included:
1x TeenyF4 Pro flight controller board
4x M2*5+5 Nylon column
4x M2 Nuts
4x M2 Screw
