12 LED BZ-TY Explosion Flashing RC Car Lamp
Description:
Input voltage: 4.8V-6.0V
Working current: 100mA
Dimension: 47*30*12mm
LED wire: 35cm
Control wire: 28cm
Power core connection wire: 20cm
Weight: 50g
Set up:
Choose a car body and install the LED holder in the car body.
Put the LED into the LED holder.
Connect each LED with the plug in the corresponding control box based on the instruction.
Stick the main control box on the top of car body properly.
Mount the car LED wire and avoid the interference of the wheels' turn or spin.
Fix all the wires and check whether they are set correctly.
*LED could be installed flexiably, according to your preference.
Modes:
After plug in, enter the car mode. Press control button "SET" to enter the following 4 modes.
All car LED is on.
For the front car LED, the White light is flashing quickly, the blue light is always on. For the back LED, the White LED is always on, the Yellow and Red lights are flashing quickly.
For the front car LED, the White and blue lights are flashing in the highest speed frequency in a loop. For the back car LED, the White, Yellow and Red lights are flashing in the highest speed frequency as well.
For the front car LED, the White LED is always on, the Yellow LED is flashing slowly. For the back car LED, the white and yellow lights are flashing at the same time, and they are flashing with Red LED alternatively.
Package includes:
12 x Car LED
12 x Car LED holder
1 x Control box
1 x Power connection
1 x Control connection
1 x Accessories parcel
