Description:
Item Name: 1/2.5" CMOS 1200TVL camera module
Item Type: video camera
Chip: 1/3 CCD 1200TVL
Sensor: CMOS
Sensor Brand: Sony
Size:38*38mm
System:NTSC / PAL
Specification:
Pixel: 1280(H)×1024(V)
Image Sensor:Sony IMAX138
Processor: FH8520
Horizontal Resolution(horizontal center: 1200TVL
Minimum Illumination:0.01 Lux / F1.2
Signal Noise Ratio: >48dB
Video Output: 1.0Vp-p / 75Ω
Auto Gain Control:Auto
White Balance: Auto
Back-light Compensation: Auto
Electronic Shutter: 1s-1/1000s
Synchronization Method: Internal Synchronization
OSD Menu: YES
Voice Frequency: NO
Operation Voltage: DC12V±5%
Operation Temperature: -20℃--60℃
Features:
- Supported OSD menu
- 3D noise reduction
- IrCOMM to Computer
- Lightning protection
- Supported IR-CUT,light board control IR-CUT:image turns to black and white when the light board is bright,makes the illumination be better.
Package Included:
1x Camera module
1x 3P plug wire
1x OSD board
1x AV cable
1x Manual
